Part numbers |
alix3c3 = 1 LAN / 2 miniPCI / LX800 / 256 MB / USB / VGA / audio |
| Spec | CPU: 500 MHz AMD Geode LX800 DRAM: 256 MB DDR DRAM Storage: CompactFlash socket Power: DC jack or passive POE, min. 7V to max. 20V Three LEDs Expansion: 2 miniPCI slots, LPC bus Connectivity: 1 Ethernet channel (Via VT6105M 10/100) I/O: DB9 serial port, dual USB, VGA, audio headphone out / microphone in RTC battery Board size: 100 x 160 mm Firmware: Award BIOS |
| Customer options | I2C bus, buzzer |
| BIOS updates | None yet. Please note that this board uses Award BIOS, tinyBIOS will not support VGA… |
