ITX Automotive M3-ATX-HV 95W 6 – 34V power supply (24V system)

775.00kr  620.00kr ex. moms

Tillgänglighet: I lager (kan restnoteras)

Artikelnr: SKU-1580 Kategori: Brand:

En ny smart version av en fordonsdatornätdel. Detta är världens mest kompakta fordonsnätdel och den är fullmatad med funktioner. Man “snäpper” fast den direkt i moderkortets ATX kontakt och den klarar ett inspänningsspann på hela 6 till 34 VDC.

– 95 Watts (120watt peak) PSU
– 20pin ATX, 6-34V wide input range
– Programmable timing settings

– Intelligent shutdown controller
– ON/OFF motherboard control
– Survives vehicle engine cranks
– Battery deep discharge prevention
– “Anti-Thump” Amplifier remote control
– Low standby current

– Solid Polymer capacitors, Japan
– VIA, Intel and AMD CPU support

This is an intelligent, high power, vehicle (car / boat / electric cart) DC-DC ATX PC power supply designed for car pc or battery powered applications. Designed to provide power and to control the ON/OFF switch of a motherboard (car PC) based on ignition status, the PSU is a wide input (6 to 34V) vehicle / car / battery operated ATX power supply capable of surviving tough car engine cranks (down to 6V) as well as transient over-voltage situations. Just connect it to your car / boat / RV / solar battery and power up your PC!

The PSU is based on similar electrical similar design as other automotive PSU:s but with dramatic size reductions (picoPSU plug-in style).

By using Patent Pending HyperWatt[TM] technologies, the PSU packs an impressive amount of power relative with its very small footprint. The PSU has several key advantages over traditional power supplies:
– Very small, can build ultra-compact PC enclosures and slim server enclosures.
– Programmable shutdown / sleep modes via optional serial cable.
– Fits any motherboard equipped with a 20 or 24pin ATX connector.
– 100% silent, fanless, no moving parts.
– Operates from 6-34V, multi-chemistry batteries supported.
– Highly efficient design, does not produce a lot of heat.
– Ideal for low power Intel as well as all VIA or AMD processors.
